Corrosion Inhibitors (HALOX)

방청제는 액체나 기체에 접촉하는 금속이나 합금 등의 물질의 부식을 방지하는 화합물이다. HALOX®는 페인트 및 코팅 시장에 방청제를 제공하는 글로벌 선도업체로서, 다양한 코팅 시장에 대응할 수 있도록 안전하고 내구성이 뛰어나며 오래 지속되는 솔루션을 제공하고 있다.

Inorganic Corrosion Inhibitors

Product Chemical Description Physical Properties
HALOX®700 Zinc Aluminum Phosphate pH (10% solution by wt) 5.1
Oil Absorption (lbs/100 lbs) 36
Density (g/ml) 3.1
D50 Horiba (microns) 5-7
D100 Horiba (microns) <20
HALOX®SZP-391 Strontium Zinc Phosphosilicate pH (10% solution by wt) 7.2
Oil Absorption (lbs/100 lbs) 34.3
Density (g/ml) 3.3
Mean Particle Size (microns) 4.9
HALOX®SZP-391 JM Strontium Zinc Phosphosilicate pH (10% solution by wt) 7.5
Oil Absorption (lbs/100 lbs) 34.0
Density (g/ml) 3.3
Mean Particle Size (microns) 2.0
HALOX®SZP-395 Strontium Zinc Phosphosilicate pH (10% solution by wt) 7.2
Oil Absorption (lbs/100 lbs) 34.0
Density (g/ml) 3.3
Mean Particle Size (microns) 4.2
HALOX®Zinc Phosphate Zinc Phosphate Complex pH (10% solution by wt) 8.2
Oil Absorption (lbs/100 lbs) 42.0
Density (g/ml) 3.2
Mean Particle Size (microns) 5.0
HALOX®Z-PLEX 111 Zinc Phosphate Complex pH (10% solution by wt) 8.1
Oil Absorption (lbs/100 lbs) 36.3
Density (g/ml) 3.0
Mean Particle Size (microns) 5.9
HALOX®Z-PLEX 250 Zinc Phosphate Complex pH (10% solution by wt) 7.5
Oil Absorption (lbs/100 lbs) 25.0
Density (g/ml) 3.3
Mean Particle Size (microns) 5.0
HALOX®Z-PLEX 750 Inorganic/Organic Phosphosilicate pH (10% solution by wt) 7.2
Oil Absorption (lbs/100 lbs) 27.0
Density (g/ml) 3.0
Mean Particle Size (microns) 5.0



Inorganic Corrosion Inhibitors (Zinc free)

Product Chemical Description Physical Properties
HALOX®430 Calcium Phosphate Based Inhibitor pH (10% solution by wt) 8
Oil Absorption (lbs/100 lbs) 45
Density (g/ml) 2.7
Mean Particle Size (microns) 4-6
HALOX®430 JM Calcium Phosphate Based Inhibitor pH (10% solution by wt) 8.0
Oil Absorption (lbs/100 lbs) 50.0
Density (g/ml) 2.7
Mean Particle Size (microns) 2.0
HALOX®BW-191 Barium Phosphosilicate pH (10% solution by wt) 8.2
Oil Absorption (lbs/100 lbs) 35.3
Density (g/ml) 3.0
Mean Particle Size (microns) 5.7
HALOX®CW-22/221 Calcium Borosilicate pH (10% solution by wt) 10.1
Oil Absorption (lbs/100 lbs) 33.1
Density (g/ml) 2.7
Mean Particle Size (microns) 5.8
HALOX®CW-2230 Calcium Borosilicate pH (10% solution by wt) 10.1
Oil Absorption (lbs/100 lbs) 37.3
Density (g/ml) 2.6
Mean Particle Size (microns) 5.5
HALOX®CW-291 Calcium Borosilicate pH (10% solution by wt) 10.1
Oil Absorption (lbs/100 lbs) 28.4
Density (g/ml) 2.7
Mean Particle Size (microns) 5.7
HALOX®CW-314 Calcium Phosphate Based Inhibitor pH (10% slurry by wt) 7.0
Oil Absorption (lbs/100 lbs) 79.5
Density (g/ml) 3.0
Mean Particle Size (microns) 5.2
HALOX®CW-491 Calcium Phosphosilicate pH (Neat) 8.0
Oil Absorption (lbs/100 lbs) 45.9
Density (g/ml) 2.7
Mean Particle Size (microns) 4.3
HALOX®SW-111 Strontium Phosphosilicate pH (10% solution by wt) 7.9
Oil Absorption (lbs/100 lbs) 45.1
Density (g/ml) 2.8
Mean Particle Size (microns) 5.9

Organic Corrosion Inhibitors (Water)

Product Chemical Description Physical Properties
HALOX®350 Organic Di-Acid pH (10wt% sol) 3.3
Active solids 97-100
Form/Appearance Powder/Slightly Yellow
Density (g/ml) 1.57
Melting point (°C) Approx. 170 (decomposition)
HALOX®515 Aminocarboxylate Salt pH (Neat) 8.9
Specific Gravity @ 25°C 1.06
Form/Appearance Liquid/Slightly Amber
Color (Lovibond) 1
% Active Solids 20.5
VOC (EPA Meth 24) (lbs/gal) 0.66
VOC (EPA Meth 24) (g/L) 79.2
HALOX®515 LFG Aminocarboxylate Salt pH (Neat) 9.7
Specific Gravity @ 25°C 1.03
Form/Appearance Liquid/Slightly Amber
Color (Lovibond) 1
VOC (EPA Meth 24) (lbs/gal) 1.88
VOC (EPA Meth 24) (g/L) 226
HALOX®570 Organic Acid Amine Complex Form/Appearance Powder/ White
Melting Range (°C) 67-63°C
Density (g/ml) 1.24
pH (10% solution by wt) 6.5
Oil Absorption (Ibs/100 Ibs) 12.9
HALOX®570 LS Organic Acid Amine Complex pH (Neat) 7.8
Specific Gravity @ 25°C 1.1
Form/Appearance Liquid/Amber
Color (Lovibond) 1
% Active Solids (ASTM D 2369) 28.9

Organic Corrosion Inhibitors (Solvent)

Product Chemical Description Physical Properties
HALOX®550 Inorganic-Organic Hybrid Corrosion Inhibitor pH (Neat) 5-8
Specific Density 0.99
Form/Appearance Liquid/Clear colorless
% Solubility 100
VOC (EPA Meth 24) (lbs/gal) 3.71
VOC (EPA Meth 24) (g/L) 445
HALOX®550 WF Water-free Inorganic-Organic Corrosion Inhibitor Specific Density 0.99
Form/Appearance Liquid/Clear colorless
% Solubility Miscible
VOC (EPA Meth 24) (lbs/gal) 8.17
VOC (EPA Meth 24) (g/L) 979
HALOX®630 Alkylammonium Salt Solution Specific Gravity @ 20°C (g/cm3) 0.99
Form/Appearance Liquid/Slightly Yellow
Dynamic Viscosity @ 20°C (mPa.s) 160
HALOX®650 Organic Di-Acid Density (g/ml) 0.99
Form/Appearance Powder/Slightly Yellow
Melting point (℃) Approx. 170 (decomposition)
HALOX®RC-980 Rust Converting Additive Specific Gravity @ 25°C 1.07
Form/Appearance Liquid/Slightly Yellow
Freeze Cycle Freeze Stable
Color (Lovibond) 2
Flash point(PMCC) (°F) >218



Flash Rust Corrosion Inhibitors

Product Chemical Description Physical Properties
HALOX®FLASH-X®150 Sodium Nitride Based Solution pH (Neat) 9.6
Specific Gravity @ 25°C 1.14
Form/Appearance Liquid/Slightly Yellow
Color (Lovibond) Light Straw
% Active Solids 24
VOC (EPA Meth 24) (lbs/gal) 0.85
VOC (EPA Meth 24) (g/L) 102
HALOX®FLASH-X®330 Alkanolamine Borate and Phosphate salts pH (Neat) 8.3
Specific Gravity @ 25°C 1.21
Form/Appearance Liquid/Clear Colorless
Color (Lovibond) Light Straw
% Active Solids 68
VOC (EPA Meth 24) (lbs/gal) 1.11
VOC (EPA Meth 24) (g/L) 133
